MTOnautic

Our remarkable floating platform.

Fitting floats give the MTOsport amazing capability to operate safely along coastlines or lakes fronts where landing and take-off from water are required. This is friendly-face coastal monitoring at its best with low noise, low carbon footprint, excellent performance, and a perfect observation platform.

Maximizing innovation and flexibility, this adaptation of the MTOsport is as versatile as it is technically thought-through and even available as an after-market kit. The Nautic offers access to a wide range of applications that require operation around and over water. The Nautic floats are semi-rigid inflatable and can be swopped with wheels with minimal tools and equipment for normal inland operations.

The MTOsport 2017 equipped with floats can land and take off safely from water, and because of the extremely slow landing speed, can also land safely on firm ground. With a fuel capacity of 96 liters, it can achieve a safe endurance of 4 hours. Our floating platform provides the best opportunity to carry out maritime missions, such as patrol, rescue, and surveillance, whether operating inland or along the coast.

Floats are also available as fully amphibious instead of convertible between floats and wheels. See the MTOamphib.

Main application areas:

  • Unique tourist experience
  • Aerial surveillance
  • Maritime, river, lake monitoring and rescue
  • Coastal patrol

The Float package is available as a new-build option or retrofit kit. Approval from local aviation authorities may be necessary.

Skymaris AutoGyro MTOnautic

Enjoy the difference

  • True 360-degrees view for maximum observation capability
  • Sea or inland water operation, take-off and landing
  • Nose mounted camera capability
  • Stainless steel unpainted airframe; easy to inspect and no corrosion
  • Rear seat observer/camera operator
  • Superb safety for offshore operations
  • Long-range 96-liter fuel tank
  • Can be supplied with dual or multiple radio systems for combined aerial and marine communications
  • No need for a lifeboat; you are flying in one!
  • A friendly face for serious coastal patrol missions.

Technical Specifications

Technical DetailsModel Details

L X W X H:

5.25 m x 1,9 m x 2,8 m
(17.06 ft x 5.85 ft x 9.1 ft)

Rotor Diameter:

8.6 m / 8.8 m
(27.95 ft / 28.6 ft)

Empty Weight:

350 kg (770 lbs)
depending on options chosen

MTOW (Max Take Off Weight):

560 -650 kg (1232 – 1430 lbs)
depending on market limitations

Engine:

Rotax 915iSc / 916 iSc

Takeoff Distance *2:

110 m (357 ft)
depending on water conditions

Max Endurance *3:

up to 5,5 hours

Max Range *3:

up to 550 km (330 miles)

Cruise Speed:

90-185 km/h (55-110mph)

Fuel Capacity:

96 ltr (25 us Gallons)

Compliant With:

BUT (Germany), Section T (UK), CRIE-01 (UK),
ASRA (Australia), USA Primary Category

Technical data can vary regarding country-specific legal requirements
*2: typical aircraft configuration, 1 pilot (80kg), 40 ltr fuel, 2000 ft MSL
*3: typical aircraft configuration, 1 pilot (80kg), max fuel, 2000 ft MSL
